DVL500 Compact, Schilling

6000 m

Tracking du fond de 0.3 à 200 m. Opérationnel jusqu'à 6000 m


The DVL500 is a universal Doppler Velocity Log that combines compact design with unprecedented functionality. It can fly higher in the water column and closer to the seabed than similar equipment, and maximum operational depth is 6000 m. This 500 kHz Doppler Velocity Log is used by industry leaders in the subsea market because of its high accuracy and state-of-the-art technology.

  • Currents
  • Bottom track

Points forts

  • Bottom track from 0.3-200 m range
  • Per-ping and per-beam data quality estimates
  • 6000 m operational depth


  • Highly accurate subsea surveys
  • AUVs with long missions or high accuracy requirements
  • Easy integration with leading inertial navigation systems (INS)


Equipped with a Seanet connector, this version of the DVL500 Compact is designed for seamless integration with TechnipFMC Schilling Robotics ROVs.


Tested in demanding conditions in the Oslo fjord, the DVL500 Compact has a proven track record in areas of variable bathymetry and conditions. The water track feature provides a velocity backup if the bottom becomes out of range. The spectrum analyzer ensures performance.


Effortless setup with dropdown menu initialization significantly reduces integration time, getting jobs up and running faster.

Télécharger le PDF

Single ping std @ 3 m/s

0.5 cm/s

Long-term accuracy

±0.1% / ±0.1 cm/s

Minimum altitude

0.3 m

Maximum altitude

175 m

Velocity resolution

0.01 mm/s

Maximum ping rate

8 Hz max

Minimum accuracy

0.3% of measured value ± 0.3 cm/s

Minimum range

4.0 m

Minimum accuracy

0.3% of measured value ± 0.3 cm/s

Velocity resolution

0.1 cm/s


User-specified Nth ping

Maximum range

70 m


0.5 m

Cell size

0.5-4.0 m

Max # cells


Operating temperature

-4 to +40 °C

Storage temperature

-20 to +60 °C



EMC approval

IEC/EN 61000-6-2, 61000-6-3

Depth rating

6000 m


5.1 kg

Weight in water

3.1 kg


212 mm


ø160 mm with connector

Frequency of operation

500 kHz

Beam width



4-beam Janus array convex transducer, 25° beam angle

Internal memory

16 GB / 64 GB optional


25% centered at transmit frequency

Serial (either serial or ethernet)

Configurable RS232 or RS422, 8-pin male


10/100 Mbits Auto MDI-X.TCP/IP, UDP/IP, HTTP protocols. Fixed IP / DHCP client /Auto IP address assignment. UPnP and Nortek proprietary instrument discovery over Ethernet. EEE1588/PTP and NTP for absolute time stamping. Multiple simultaneous data format transmission possible.

Data formats

Nortek proprietary w/ 1 ms time stamp accuracy, NMEA0183, Variants of PDx


Internal 1, 2, 3, 4, 5, 6, 7 or 8 Hz or Trigger In. Trigger option through command (Ethernet or serial) External TTL or 485 lines: (configurable Rising/Falling/Edges)


0.1% FS /precision better than 0.002% of full scale per sample


-4° to 40 °C ± 0.1 °C

DC input

12-48 V

Maximum continuous current

1.5 A

Average power

3.0 W*

  • Power based on 1 Hz sampling and altitude with greatest transmit pulse.


POM and titanium housing

Schilling DVL500 Compact 6000m (2024 onward)
DVL 500KHZ, 6000m General Arrangement - NGA032-003 Rev.B

End User Declaration - Nortek DVL
Declaration of conformity

DVL500, 6000m

4 beam head

Titanium housing 6000M

16 GB SD card data logger

64 GB

Pressure sensor 0-10 m, 0,1%

Pressure sensor 0-20 m, 0,1%

Pressure sensor 0-30 m, 0,1%

Pressure sensor 0-50 m, 0,1%

Pressure sensor 0-100 m, 0,1%

Pressure sensor 0-200m, 0,1%

Pressure sensor 0-500m, 0,1%

Pressure sensor 0-1000m, 0,1%

Pressure sensor 0-4000m, 0,1%

Pressure sensor 0-6000m, 0,1%

Cable, 8 pin female ethernet AD2CP with RS485 trigger

Cable, 8 pin female serial AD2CP with RS485 trigger

Cable, 8 pin female ethernet AD2CP with TTL trigger

Cable, 8 pin female serial AD2CP with TTL trigger

Bottom track

Current profiles, 4 beams
