DOPPLER VELOCITY LOG

DVL500 Compact, Schilling - 6000 m

Bottom-track from 0.3 to 175 m range; 6000 m operational depth, Seanet connector.

  • Specially equipped with Seanet connector for TechnipFMC's Schilling Robotics ROVs
  • Bottom-track from 0.3 to 175 m range
  • Per-ping and per-beam data quality estimates
Request a quote
Technical specification (PDF)
get help

Need Help? Get in touch.

Overview

  • This special version of the DVL500 Compact comes fitted with a Seanet connector, allowing for seamless integration with TechnipFMC's Schilling Robotics work-class ROVs. Nortek has worked closely with TechnipFMC Schilling Robotics to extensively test and integrate this DVL with their ROVs, enabling users to enjoy extended range in a compact package.

    The DVL500 Compact combines the compact design of the standard DVL1000 with the superior bottom-track range of the DVL500.

Highlights

  • Specially equipped with Seanet connector for TechnipFMC's Schilling Robotics ROVs
  • Bottom-track from 0.3 to 175 m range
  • Per-ping and per-beam data quality estimates

Applications

  • Work-class ROV integration

    • Toggle all

    • Bottom velocity

      Single ping std @ 3 m/s 0.5 cm/s
      Long-term accuracy ±0.1% / ±0.1 cm/s
      Minimum altitude 0.3 m
      Maximum altitude 175 m
      Velocity resolution 0.01 mm/s
      Maximum ping rate 8 Hz max

    • Water tracking

      Minimum accuracy 0.3% of measured value ± 0.3 cm/s
      Minimum range 4.0 m

    • Current profiling

      Minimum accuracy 0.3% of measured value ± 0.3 cm/s
      Velocity resolution 0.1 cm/s
      Interval User-specified Nth ping
      Maximum range 70 m
      Blanking 0.5 m
      Cell size 0.5-4.0 m
      Max # cells 140

    • Environmental

      Operating temperature -4 to +40 °C
      Storage temperature -20 to +60 °C
      Vibration IEC60068-2-64
      EMC approval IEC/EN 61000-6-2, 61000-6-3

    • Mechanical

      Depth rating 6000 m
      Weight 5.1 kg
      Weight in water TBD
      Height 212 mm
      Diameter ø160 mm with connector

    • Hardware

      Frequency of operation 500 kHz
      Beam width 5.8°
      Configuration 4-beam Janus array convex transducer, 25° beam angle
      Internal memory 16 GB / 64 GB optional
      Bandwidth 25% centered at transmit frequency

    • Interfaces

      Serial (either serial or Ethernet) Configurable RS232 or RS422, Seanet connector
      Ethernet 10/100 Mbits Auto MDI-X.TCP/IP, UDP/IP, HTTP protocols. Fixed IP / DHCP client /Auto IP address assignment. UPnP and Nortek proprietary instrument discovery over Ethernet. EEE1588/PTP and NTP for absolute time stamping. Multiple simultaneous data format transmission possible.
      Data formats Nortek proprietary w/ 1 ms time stamp accuracy, NMEA0183, variants of PDx
      Trigger Internal 1, 2, 3, 4, 5, 6, 7 or 8 Hz or Trigger In. Trigger option through command (Ethernet or serial) External TTL or 485 lines: (configurable Rising/Falling/Edges)

    • Sensors

      Pressure 0.1% FS /precision better than 0.002% of full scale per sample
      Temperature -4° to 40 °C ± 0.1 °C

    • Power

      DC input 12-48 V
      Maximum continuous current 1.5 A
      Average power 3.0 W*
      * Power based on 1 Hz sampling and altitude with greatest transmit pulse.

    • Materials

      Materials POM and titanium housing

    • Toggle all

    • Technical drawings

      Schilling DVL 500 MK3, 6000m General Arrangement - NGA032-024 Rev B

      Download this

    • Approvals

      End User Declaration - Nortek DVL

      Download this

      Declaration of conformity

      Download this

    • Toggle all

    • Main product

      01

      DVL500, 6000m

    • Probe type / Head

      01

      4-beam head

    • Housing

      01

      Titanium housing 6000 m

    • Memory

      01

      16 GB SD card data logger

      02

      64 GB

    • Pressure sensors

      01

      Pressure sensor 0-10 m, 0.1%

      02

      Pressure sensor 0-20 m, 0.1%

      03

      Pressure sensor 0-30 m, 0.1%

      04

      Pressure sensor 0-50 m, 0.1%

      05

      Pressure sensor 0-100 m, 0.1%

      06

      Pressure sensor 0-200m, 0.1%

      07

      Pressure sensor 0-500m, 0.1%

      08

      Pressure sensor 0-1000m, 0.1%

      09

      Pressure sensor 0-4000m, 0.1%

      010

      Pressure sensor 0-6000m, 0.1%

    • Cables

      01

      Cable, 8-pin female Ethernet AD2CP with RS485 trigger

      02

      Cable, 8-pin female serial AD2CP with RS485 trigger

      03

      Cable, 8-pin female Ethernet AD2CP with TTL trigger

      04

      Cable, 8-pin female serial AD2CP with TTL trigger

    • Other

      01

      Bottom track

      02

      Current profiles, 4 beams
