Aquadopp Profiler Z-Cell 600kHz - Obsolete

Overview

This version of the Aquadopp Profiler Z-Cell is no longer available.

Please see the Aquadopp Profiler Z-Cell 2.

This version of the Aquadopp remains functional and supported. Please visit our support center if you require assistance.

Download PDF

Maximum profiling range

30-40 m

Cell size

1-4 m

Minimum blanking

0.50 m when profiling; 0 m when Z-Cell enabled

Maximum number of cells

96

Measurement cell position

N/A

Default position (along beam)

N/A

Velocity range

±10 m/s

Accuracy

±1% of measured value ±0.5 cm/s

Velocity precision

Consult instrument software

Maximum sampling rate (output)

1 Hz

Internal sampling rate

3 Hz

Cell zero acoustic frequency

2 MHz

Maximum profiling range

0.4-0.9 m

Number of beams

2

Sampling

Same as velocity

Resolution

0.45 dB

Dynamic range

90 dB

Transducer acoustic frequency

600 kHz

Number of beams

3

Beam width

3.0°

Temperature:

Thermistor embedded in head

Temp. range

-4 to +40 °C

Temp. accuracy/resolution

0.1 °C/0.01 °C

Temp. time response

10 min

Compass:

Magnetometer

Accuracy/resolution

2°/0.1° for tilt < 20°

Tilt:

Liquid level

Accuracy/resolution

0.2°/0.1°

Maximum tilt

30°

Up or Down

Automatic detect

Pressure:

Piezoresistive

Range

0-100 m (inquire for options)

Accuracy/precision

0.5% FS / 0.005% of full scale

Capacity

9 MB, can add 4/16 GB

Data record

9*Ncells + 32 bytes

Diagnostics record

N/A

Wave record

Nsamples * 24 + 60 bytes

Mode

Stop when full (default) or wrap mode

Accuracy

±1 min/year

Backup in absence of power

4 weeks

I/O

RS-232 or RS-422

Communication baud rate

300-115200 Bd

Recorder download baud rate

600/1200 kBd for both RS-232 and RS-422

User control

Handled via "Aquadopp" software, ActiveX®function calls, or direct commands with binary or ASCII data output

Functions

Deployment planning, instrument configuration, data retrieval and conversion (for Windows®)

DC input

9-15 V DC

Maximum peak current

3 A

Avg. power consumption

0.06 W

Sleep current

< 100 μA

Transmit power

0.3-20 W, 3 adjustable levels

Battery capacity

50 Wh (alkaline or Li-ion), 165 Wh (lithium), Single or dual

New battery voltage

13.5 V DC

Operating temperature

-5 to +40 °C

Storage temperature

-20 to +60 °C

Shock and vibration

IEC 721-3-6

EMC approval

IEC 61000

Depth rating

300 m

Bulkhead

MCBH-8-FS

Cable

PMCIL-8-MP on 10 m polyurethane cable

Standard model

POM and polyurethane plastics with titanium fasteners

Maximum diameter

100 mm

Maximum length

~550 mm (single battery), +110 mm (double battery) depending on head configuration

Weight in air

2.9 kg

Weight in water

0.4 kg

Z-Cell 600KHz General Arrangement - NGA011-020 Rev.-

Declaration of conformity

9 MB of memory on motherboard (M8)

4 GB SD card data logger

16 GB SD card data logger

10m RS232 polyurethane cable with 8-pin inline connector and USB converter

20m RS232 polyurethane cable with 8-pin inline connector and USB converter

30m RS232 polyurethane cable with 8-pin inline connector and USB converter

40m RS232 polyurethane cable with 8-pin inline connector and USB converter

50m RS232 polyurethane cable with 8-pin inline connector and USB converter

10m RS422 polyurethane cable with 8-pin inline connector and USB converter

20m RS422 polyurethane cable with 8-pin inline connector and USB converter

30m RS422 polyurethane cable with 8-pin inline connector and USB converter

40m RS422 polyurethane cable with 8-pin inline connector and USB converter

50m RS422 polyurethane cable with 8-pin inline connector and USB converter

Also compatible with Z-cell. New features, fixes and functionality

Deployment planning, execution and recovery

Display of profiler data. Can be used in combination with Prof2NDP

Data conversion

Processing of waves

Data processing and ready-to-print reporting software. Request quote for license

Wave and current profile data visualization and processing software for online applications. Request quote for license

Analysis and processing of currents and directional waves. Request quote for license

Analysis and processing of current profiles. Request quote for license

320051

Cable for external battery canister to 8-pin inline connector

650001

Cable RS232 polyurethane with 8-pin inline connector and USB converter

650072

Cable RS422 polyurethane with 8-pin inline connector and USB converter

220010

Battery, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008

Battery, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220025

Battery, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.

901115

Battery canister, plastic with 4*18 AA pack w/cable 8-pin inline (300m rating)

220010 5 Pack

Battery pack, 5-pack, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220010 10 Pack Nortek batteries

Battery pack, 10-pack, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008 5 Pack

Battery pack, 5-pack, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008 10 pack batteries

Battery pack, 10-pack, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220025 5 Pack

Battery pack, 5-pack, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.

Nortek battery packs

Battery pack, 10-pack, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.
