Aquadopp Profiler Z-Cell 1 MHz - Obsolete

Overview

This version of the Aquadopp Profiler Z-Cell is no longer available.

Please see the Aquadopp Profiler Z-Cell 2.

This version of the Aquadopp remains functional and supported. Please visit our support center if you require assistance.

Download PDF

Maximum profiling range

12-25 m

Cell size

0.3-4 m

Minimum blanking

0.20 m when profiling; 0 m when Z-Cell enabled

Maximum number of cells

96

Measurement cell position

N/A

Default position (along beam)

N/A

Velocity range

±10 m/s

Accuracy

±1% of measured value ±0.5 cm/s

Velocity precision

Consult instrument software

Maximum sampling rate (output)

1 Hz

Internal sampling rate

6 Hz

Distance to measurement volume

0.05 - 2.5 m

Cell size

0.2 - 1.5 m

Velocity range (Horizontal)

±5 m/s

Transducer acoustic frequency

2 MHz

Number of beams

2

Sampling

Same as velocity

Resolution

0.45 dB

Dynamic range

90 dB

Transducer acoustic frequency

1 MHz

Number of beams

3

Beam width

3.4°

Maximum profiling range

6 m

Cell size

20-300 mm

Minimum blanking

0.2 m

Maximum number of cells

128

Range/Velocity limitations

Product of profiling range and velocity should not exceed 1.0 m2/s

Accuracy

±1% of measured value ±0.5 cm/s

Max. sampling rate

1 Hz (continuous mode), 8 Hz (burst mode)”

Temperature:

Thermistor embedded in head

Temp. range

-4 to +40 °C

Temp. accuracy/resolution

0.1 °C/0.01 °C

Temp. time response

10 min

Compass:

Magnetometer

Accuracy/resolution

2°/0.1° for tilt < 20°

Tilt:

Liquid level

Accuracy/resolution

0.2°/0.1°

Maximum tilt

30°

Up or Down

Automatic detect

Pressure:

Piezoresistive

Range

0-100 m (inquire for options)

Accuracy/precision

0.5% FS / 0.005% of full scale

Capacity

9 MB, can add 4/16 GB

Data record

9*Ncells + 32 bytes

Diagnostics record

N/A

Wave record

Nsamples * 24 + 60 bytes

Mode

Stop when full (default) or wrap mode

Accuracy

±1 min/year

Backup in absence of power

4 weeks

I/O

RS-232 or RS-422

Communication baud rate

300-115200 Bd

Recorder download baud rate

600/1200 kBd for both RS-232 and RS-422

User control

Handled via "Aquadopp" software, ActiveX®function calls, or direct commands with binary or ASCII data output

Functions

Deployment planning, instrument configuration, data retrieval and conversion (for Windows®).

DC input

9-15 V DC

Maximum peak current

3 A

Avg. power consumption

0.05 W

Sleep current

< 100 μA

Transmit power

0.3-20 W, 3 adjustable levels

Battery capacity

50 Wh (alkaline or Li-ion), 165 Wh (lithium), Single or dual

New battery voltage

13.5 V DC (alkaline)

Operating temperature

-5 to +40 °C

Storage temperature

-20 to +60 °C

Shock and vibration

IEC 721-3-7

EMC approval

IEC 61000

Depth rating

300 m

Bulkhead

MCBH-8-FS

Cable

PMCIL-8-MP on 10 m polyurethane cable

Bulkhead

MCBH-8-FS

Cable

PMCIL-8-MP on 10 m polyurethane cable

Bulkhead

MCBH-8-FS

Cable

PMCIL-8-MP on 10 m polyurethane cable

Weight in air

2.2 kg

Weight in water

0.2 kg

Z-Cell 1MHz, General Arrangement - NGA011-019 Rev.-

Declaration of conformity

Also compatible with Z-cell. New features, fixes and functionality

Deployment planning, execution and recovery

Display of profiler data. Can be used in combination with Prof2NDP

Data conversion

Processing of waves

Data processing and ready-to-print reporting software. Request quote for license

Wave and current profile data visualization and processing software for online applications. Request quote for license

Analysis and processing of currents and directional waves. Request quote for license

Analysis and processing of current profiles. Request quote for license

320051

Cable for external battery canister to 8-pin inline connector

650001

Cable RS232 polyurethane with 8-pin inline connector and USB converter

650072

Cable RS422 polyurethane with 8-pin inline connector and USB converter

220010

Battery, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008

Battery, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220025

Battery, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.

901115

Battery canister, plastic with 4*18 AA pack w/cable 8-pin inline (300m rating)

220010 5 Pack

Battery pack, 5-pack, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220010 10 Pack Nortek batteries

Battery pack, 10-pack, 13.5 V - 50 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008 5 Pack

Battery pack, 5-pack, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220008 10 pack batteries

Battery pack, 10-pack, 13.5 V - 100 Wh, alkaline - for use with discontinued Aquadopp

This slim battery can be used inside the main canister of your Nortek instrument.

220025 5 Pack

Battery pack, 5-pack, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.

Nortek battery packs

Battery pack, 10-pack, 12 V - 165 Wh, lithium - for use with discontinued Aquadopp

This battery can be used inside the main canister of your Nortek instrument.

650246

Set of Anti-fouling patches for Aquadopp Profiler Z-cell 1 MHz

This set is suitable for Aquadopp Profiler Z-cell 1 MHz
