Overview
The Vector is a high-accuracy single-point current meter that is capable of acquiring 3D velocity in a very small volume at rates up to 64 Hz. It is widely used for sediment transport applications, small-scale turbulence measurements and coastal engineering studies. It has an excellent track record of delivering outstanding data quality in a variety of applications. This titanium version of the Vector is suitable for investigating deep-water currents down to depths of 4000 m.
- Currents
- Turbulence
Highlights
-
Small-scale turbulence
-
Sampling up to 64 Hz
-
Small sampling volume for measurements close to boundaries
Usage
-
Studies of bottom boundary layers
-
Studies of deep-water currents
-
Low flow measurements
Setup
This 4000m-rated velocimeter is set up using the Nortek deployment software, where users can customize the sampling rate (up to 64Hz), sampling volume size and coordinate system, especially relevant with the cabled probe option.
Deployment
Designed for small-scale turbulence sampling or collecting measurements near boundaries and in deep water, the Vector velocimeter offers multiple probe options (fixed or cabled) making for very flexible deployment setups.
Data
The Vector provides precise, rapid velocity measurements from a very small sampling volume of water. Users can resolve small-scale turbulence events and measure in areas traditionally difficult for ADCPs.
Maximum profiling range |
N/A |
Distance from probe |
0.15 m |
Sampling volume diameter |
15 mm |
Sampling volume height (user-selectable) |
5-20 mm |
Cell size |
N/A |
Velocity range |
±0.01, 0.1, 0.3,1, 2, 4, 7 m/s (software-selectable) |
Adaptive ping interval |
N/A |
Accuracy |
±0.5% of measured value ±1 mm/s |
Velocity precision |
typ. 1% of velocity range (at 16 Hz) |
Sampling rate (output) |
1-64 Hz |
Internal sampling rate |
100-250 Hz |
Minimum range |
N/A |
Maximum range |
N/A |
Cell size |
N/A |
Accuracy |
N/A |
Sampling rate |
N/A |
Acoustic frequency |
6 MHz |
Resolution |
0.45 dB |
Dynamic range |
90 dB |
Temperature: |
Thermistor embedded in end bell |
Temp. range |
-4 to +40 °C |
Temp. accuracy/resolution |
0.1 °C/0.01 °C |
Temp. time response |
10 min |
Compass: |
Magnetometer |
Accuracy/resolution |
2º/0.1º for tilt < 20° |
Tilt: |
Liquid level |
Accuracy/resolution |
0.2°/0.1° |
Maximum tilt |
30° |
Up or Down |
Automatic detect |
Pressure: |
Piezoresistive |
Range |
0-4000 m |
Accuracy/precision |
0.5% FS / Better than 0.005% of full scale |
No. of channels |
2 |
Supply voltage to analog output devices |
Three options selectable through firmware commands: 1) Battery voltage/500 mA, 2) +5 V/250 mA, 3) +12 V/100 mA |
Capacity (standard): |
16 GB |
Data record (Standard) |
24 bytes at sampling rate + 28 bytes/second |
Data record (IMU) |
72 bytes at sampling rate |
Accuracy |
±1 min/year |
Backup in absence of power |
4 weeks |
I/O |
RS-232 or RS-422 |
Communication baud rate |
300-115 200 Bd |
Recorder download baud rate |
600/1200 kBd for both RS-232 and RS-422 |
User control |
Handled via ”Vector” software, ActiveX® function calls, or direct commands. |
Analog outputs |
3 channels standard, one for each velocity component or two velocities and pressure. |
Output range |
0–5 V, scaling is user-selectable. |
Synchronization |
TTL (5 V tolerant) sync in/sync out, start on sync, sample on sync |
Bulkhead |
MCBH-8-FS |
Cable |
PMCIL-8-MP on 10 m polyurethane cable |
Functions |
Deployment planning, instrument configuration, data retrieval and conversion (for Windows®). |
Software |
N/A |
I/O |
N/A |
DC input |
9-15 V DC |
Maximum peak current |
3 A |
Max. consumption |
1.5 W at 64 Hz |
Typical consumption, 4 Hz |
0.6 - 1 W |
Sleep consumption |
< 100 μA |
Transmit power |
2 adjustable levels |
Battery capacity |
50 Wh (alkaline or Li-ion),165 Wh (lithium), single or dual |
New battery voltage |
13.5 V DC (alkaline) |
Data collection capacity |
Refer to planning section in software |
Operating temperature |
-4 to +40 °C |
Storage temperature |
-20 to +60 °C |
Vibration |
IEC 60068-1/IEC60068-2-64 |
Depth rating |
4000 m |
Standard model |
Titanium housing. Titanium probe and fasteners |
Maximum diameter |
84 mm |
Maximum length |
485 mm (housing only), 246 mm (fixed stem) add 110 mm for double battery |
Weight in air |
8.3 kg |
Weight in water |
5.1 kg |
Probe mounted on fixed stem or on 2 m cable |
|
Vertical or horizontal probes |
|
Alkaline, lithium or Li-ion external batteries |
|
IMU - Inertial Measurement Unit |
Vector single point current meter, 4000m pressure rating
Standard probe on fixed stem, vertical instrument mounting (VEC)
Standard probe on fixed stem, horizontal instrument mounting (VEH)
Standard housing for two batteries or one 100Wh package
Short housing for one battery
16 GB SD card data logger
0-10m pressure sensor
0-20m pressure sensor
0-30m pressure sensor
0-50m pressure sensor
0-100m pressure sensor
0-200m pressure sensor
0-4000m pressure sensor (4000m version only)
10m RS232 polyurethane cable with 8-pin inline connector and USB converter
20m RS232 polyurethane cable with 8-pin inline connector and USB converter
30m RS232 polyurethane cable with 8-pin inline connector and USB converter
40m RS232 polyurethane cable with 8-pin inline connector and USB converter
50m RS232 polyurethane cable with 8-pin inline connector and USB converter
10m RS422 polyurethane cable with 8-pin inline connector and USB converter
20m RS422 polyurethane cable with 8-pin inline connector and USB converter
30m RS422 polyurethane cable with 8-pin inline connector and USB converter
40m RS422 polyurethane cable with 8-pin inline connector and USB converter
50m RS422 polyurethane cable with 8-pin inline connector and USB converter
With or without IMU
With or without compass and tilt
Converts Vector (.vec) files to .adv
Converts PolySync Vectrino (.vno) files to .adv
Converts Aquadopp (.aqd) and Vector (.vec) wave burst data to AWAC (.wpr) format
Virtual COM port driver to allow Nortek's serial-to-USB converters to function.
Deployment planning, execution and recovery
